Specifications:
1)Lead Type :Integrated ECG electrodes
External ECG cable and electrodes
2)Display Gain:1.25 mm/mV, 2.5 mm/mV, 5 mm/mV10 mm/mV, 20 mm/mV
3)Band Width:0.05 to 40 Hz
4)Lead Set:Lead I, lead II
5)Sweep Speed:25 mm/s
6)Electrode Offset Potential Tolerance:±300 mV
7)Measure Mode:Episode, continuous
8)Accuracy:±2 bpm or ±2%, whichever is greater
9)Sampling Rate:500Hz
10)HR Measurement Range:30 to 250 bpm
11)Sampling Accuracy:16 bit
12)ST Measurement Range:-0.5 to +0.5 mV
13)Measurement Summary:Heart rate**, QRS duration, ST segment***,QT/QTc Rhythm analysis(Regular ECG Rhythm, High Heart Rate, Low Heart Rate,
High QRSValue, High ST Value***, Low ST Value***, Irregular ECG Rhythm,Unable to analyze)
Notes:
1.Price item:all above products are standard FOB price with standard accessories.
2.OEM service: can do OEM,ODM service.
3.Payment:TT,30% deposit in advance,70% balance before shipping.
4.Lead time:25-30days on receipt of delivery
5.Certificates:all the products have passed the CE,ISO certification.
When customers need large amount, we can offer better offers,pls feel free to contact us.
